倍福BECKHOFF EL9410

EL9410 | Power supply terminal for E-bus, with diagnostics

The EL9410 power supply terminal is used to refresh the E-bus. Data is exchanged between the coupler and the EtherCAT Terminal over the E-bus. Each terminal draws a certain amount of current from the E-bus (see “current consumption E-bus” in the technical data). This current is fed into the E-bus by the relevant coupler’s power supply unit. In configurations with a large number of terminals it is possible to use the EL9410 in order to supply an extra 2 A to the E-bus. The EL9410 has a diagnostic function which is displayed by LED and on the process image.

EL9410|E總線電源端子，帶診斷

EL9410電源端子用于刷新E總線。耦合器和EtherCAT終端之間通過E總線交換數據。每個終端從E總線中汲取一定量的電流（請參閱技術數據中的“電流消耗E總線”）。該電流通過相關耦合器的電源單元饋入E總線。在具有大量端子的配置中，可以使用EL9410為E總線提供額外的2A。EL9410具有診斷功能，該功能由LED和過程圖像顯示。

倍福BECKHOFF EL9410 文章出自長欣工控轉載請附上鏈接
